Vent Axia Lo-Carbon CWH L SELV Sentinel Kinetic MVHR Cooker Hood (White Left)

Product Part Number

477003

Product Overview

The Vent-Axia Lo-Carbon Sentinel Kinetic CWH L SELV is a mechanical ventilation with heat recovery unit designed with an integrated white cooker hood canopy for kitchen installations.

This left-hand SELV model combines whole-house heat recovery ventilation with a practical built-in cooker hood, making it ideal for new build properties, apartments and energy-efficient homes where ventilation performance and space-saving installation are both important.

The unit is designed to fit within a 600mm wide aperture above a hob and can be connected using horizontal, vertical or combined ducting options. When the cooker hood is opened, the MVHR unit automatically switches to boost speed, while the summer bypass opens to help prevent cooking by-products from entering the heat recovery cell.

The cooker hood includes two removable flat metal grease filters, low energy light bulbs, an integral fire damper and a thermal cut-out fuse for additional safety. As an SELV version, it allows the clearance above an electric hob to be reduced from 650mm to 550mm, making it useful for kitchen layouts where installation space is limited.

Technical Specification

Product Type: MVHR unit with integrated cooker hood

Manufacturer: Vent-Axia

Product Range: Lo-Carbon Sentinel Kinetic Cooker Hood

Model: Lo-Carbon Sentinel Kinetic CWH L SELV

Finish: White

Handing: Left-hand model

Ventilation Type: Mechanical Ventilation with Heat Recovery, MVHR

Application: Kitchen / whole-house ventilation

Sector: New build

Ducting Connection Size: 125mm

IP Rating: IP22

Ducting Options: Horizontal, vertical or combined ducting connections

Cooker Hood Features: Telescopic cooker hood canopy with two removable flat metal grease filters and low energy light bulbs

Controls: Integrated digital controller for commissioning and operation

Control Options: Plug-and-play controls, humidistat, BMS connectivity, LS input / light switch input and volt-free inputs

Timer Function: Adjustable delay-on and delay-off timer

Fault Finding: Self-diagnosis feature for simplified fault finding

Boost Function: Opening the cooker hood activates boost speed on the MVHR unit

Summer Bypass: Opens automatically when the cooker hood is activated to help prevent cooking by-products entering the heat recovery cell

Weight: 27kg

Condensate Connection: Can be taken through the rear of the unit or through the side into an adjacent cupboard before connection to a domestic waste water system

Suitable For: Kitchen installations requiring heat recovery ventilation with an integrated cooker hood

Installation Note: Cooker hood units are handed and cannot be changed on site, so this model should be ordered where a white left-hand SELV unit is required.
